Dimensions
1 PU
30 mm deep
Price
$900 Price in €

Available as an assembled Module and as a DIY project.

This Module is currently available.

Specs are approved by the manufacturer

Voltage Circus & Electric Dompteur - h series DIY

hVC
6 channel voltage mixer, adder and subtractor
Basically an Abacus for control voltages
The Voltage Circus consists of two rows of 3 voltage inputs and outputs that can be chained together.
Voltages can be added , subtracted or offset per channel.
The inputs and outputs are buffered and can be connected with shorting bars.
A switch limits each rom to provide 100% or 33% to the mixer channel to make subtraction possible or prevent clipping.
One use of the hVC is for example transposing of sequences, adding subtle animation to pitch signals or mix wild CVs to provide complex noise sources

hED
The Electric Dompteur is a swarm LFO
One master frequency, set by a knob or an external input is re-used 7 times
The 8 frequencies can be offset in phase or frequency, always based on the master frequency.
It can go down to 0 Hz and freeze the levels at their present state
And every output can be adjusted directly at the output without the need for attenuators

Both modules are also available as high quality DIY kits for 150€
2mm matte green PCBs, ENIG gold finish and the same front panels we use for the big modules.
Kits are available with extensively picture ladden building guides and all tech info is provided as well
https://northernlightmodular.com/product-category/diy-kits/
Also there will be workshops in the US and Europe where we show you how to build those.

https://www.facebook.com/NorthernLightModular

https://northernlightmodular.com/product-category/h-series/


submitted Mar 16th 2018, 13:07 by N_L_M | last Change Nov 1st 2019, 23:05 by N_L_M
