Multiple dual channel, two parts, Latching & Momentary switch

Passive mult. dual channels in two parts, Latching & Momentary

Alternative version to "Passive multiple dual channels in two parts":
Passive multiple dual channels in two independent parts with LED indication of the selected channel (led colors paired for the two parts) with LATCHING & MOMENTARY switchs:

Upper part:
Latching switchs
blue=channel A, green=channel B. Led off, the signal is muted.

Lower part:
Momentary switchs (When you release the lever, it returns to its central position. This creates momentary effects or actions!)
Red=channel A, yellow=channel B. Led off, the signal is muted.

Customization option (+4€): I can replace the switches of your choice ("latching" by default: on-off-on = 3 positions maintained) by "momentary" (when you release the lever, it returns to its initial central position). For example, Upper part : latching & Lower part, momentary or 1 switches per part can be momentary etc... It all depends on the use you are considering ...

• 4 jack's IN/OUT per part
• 2 channel's (A&B) & a central position "off" per part
• Bicolore LED's
• Latching switch's
• Skiff friendly
• Black or white panel

The price includes: module, screw M3 and connection cable. Excluding shipping costs !!
Manufactured by ph Neutre
Available as an assembled Module, no kit.

Also available in white panel :

To order, please contact me ([email protected]) the terms of payment, delivery times and shipping costs, will be detailed by return mail.
The payment will be in euros (€) and can be done by paypal. Delivery possible in the world, please contact me ([email protected])
Shipping costs :
