Dimensions
8 HP
26 mm deep
Current Draw
45 mA +12V
25 mA -12V
0 mA 5V
Price

Module is available as a DIY project only.

This Module is currently available.

Specs are approved by the manufacturer

Transistor Ladder VCF

Transistor Ladder VCF

  • VCF based on the Moog Transistor Ladder Filter
  • Compensation for loss of bass in high resonace settings via potentiometer
  • 6,12,18,24 dB/Oct selectable via potentiometer or CV!
  • 2 Inputs with attenuator for audio and CV
  • Seperate V/Oct input.
  • Input-Drive indicator LED
  • 8HP
  • DIY only,PCB+Panel
  • small and dense SMD build (0603, SOIC, SOT-363!)
  • Open source CC BY-NC-SA 4.0
  • Quick demo:

https://www.modwiggler.com/forum/viewtopic.php?f=17&t=244412&start=25

https://github.com/Cs4System/Eurorack/tree/main/Transistor_Ladder_VCF


submitted Feb 14th 2021, 10:26 by Cs4System | last Change Jun 11th 2021, 20:02 by Cs4System
