JCS Kick Drum Eurorack Module

JCS Kick Drum Eurorack Module

The Jake’s Custom Shop Kick Drum eurorack module is an 808 style kick drum with Pitch, Decay, Tone, a Clipper Switch and Level controls. Perfect for creating deep beats and adding rhythm to your system.

ELECTRICAL CHARACTERISTICS
Current Draw [mA]

+12V 8.5-9
+5V 0
-12V 8-8
Kick Drum Out 0-10.5v
Trigger Input 3-12v
Frequency 35-133 Hz
Decay Time 60-600 ms

MECHANICAL DATA
PCB dimensions 29 x 100 mm
Panel dimensions 30 x 128.5 mm (6HPX3U)
Depth of panel 15mm

https://jakescustomshop.com/Pedalboards/KickDrum/Kickdrum-Listing.html
